Working distance

50.5mm(from the patient's corneal to the aspheric lens)

Pupillary distance

Adjustable from 52-74mm

Intensity of illumination

Stepless adjustable with the maximum intensity not less than 500Lx

Lathe-hedd

530-630mm in circumference,85-125mm in depth

Light spots

Three spots, big, middle and small

Filters

Three filters including redfree, colourless and cobalt blue

Demonstrating mirror

Coated mirror with both sides viewing

Power supply of illumination

mini halogen bulb 6V/10W

Input power

20VA

Action temperature of transformer hot circuit breaker

130℃

Main part's dimension

142X48X128mm

Main part's weight

230g
