Up/Down angle of swing arm

±30°

Table size

840mm×405mm

Table rotational angle

90°

Table sliding movement

330mm

Angle of rotation for chair

±60°

Lifting height for chair

150~200mm

Loading for chair

70 ~150kgs（electric）
70 ~200kgs（hydraulic）

Lifting height for pillow

＋150mm

Backrest obliquity ( manual)

90°~135°or 140°

Electrical Parameters

Engine power

160W

Light luminaire

16W 110V/220V AV

Fuse

5A 250V AC

Power without load

1W

Pressure test

2KV

Main wire

10A 250V

Figure size:

1400mm×1000mm×1990mm

Weight:

175kgs
