Microscope type:

Galilean system

Magnification changer:

Five (5) Step Revolving drum

Total magnification:

6X,10X,16X,25X,40X

Ocular magnification:

12.5 X

Inter pupillary distance:

52mm～78mm

Diopter adjustment

+6D to -6D

Field of view

34.7mm(6X),22mm(10X),13.5mm(16X),8.5mm(25X),5.5mm(40X)

Slit illumination

Slit image width:

0～14mm continuous         (slit becomes a circle at 14mm)

Slit image length:

1～14mm continuous

Light Spot Diameter (mm)

Φ14, Φ10, Φ5, Φ3, Φ2, Φ1, Φ0.2

Slit Inclination

5°、10°、15°、20°

Slit image radial range:

0～180°

Filters:

Heat aborption,grey,redfree(green),cobalt blue

Illumination intensity:

≥50KLX

Instrument base

Range of adjustment:

90mm(longitudinal)

100mm(lateral)

30mm(vertical)

15(fine)

Chin-rest

Fixation:

LED

Vertical adjustment:

80mm

Power Supply

Output power:

30VA(max)

Output voltage:

Light source 6V continuous,fixation 3V
