Magnifications

2 step magnifications

Eyepiece

10x

Magnification Ratio
(Field of view )

16×（φ14.5mm）、10×（φ18）、

PD adjustment

52mm ~ 80mm

Diopter adjustment

+5D ~ -5D

Base

Left and right move

110mm

Forward and back move

90mm

Up and down move

30mm

Chin rest

Up and down move

80mm

Fixation lamp

Red LED

Property of illumination

Slit width

0 ~ 10mm continuous (at 10，slit becomes a circle)

Slit hight

1 ~ 10mm continuous

Slit Angle
Slit Beveling
Light spot diameter

0 ~ 1800 adjustable
0 -230
Ф10 、Ф7、 Ф5 、 Ф3, 、Ф1 、Ф0.2mm

Filter

Heat Absorption ,Grey ,Red-free ,Cobalt Blue

Illumination Bulb

12V 50W halogen lamp

Power

Input Voltage
Frequency
Power Consumption

220V
50H
68VA

Weight and size

G.W
N.W

18kg
16kg

Main Dimension

680mm（L）× 440mm（W）× 420mm（H）
