Left/Right angle of swing arm:

±30º

Angle of rotation for swing arm right-angle rack:

360º

Angle of rotation for Table:

90º

Slide-board Slippage Range:

500mm

Lifting height for chair:

150~200mm

Loading for chair:

70~150kgs

Electrical Parameters

Input voltage:

110V/220V AC 50Hz~60Hz

Engine power:

55W 24V DC

Light luminaire:

18W 250V

Fuse:

5A 250V AC

Power without load:

1W

Pressure test:

2KV

Main wire:

10A 250V

Working mode:

S1

Working temperature:

－30º~＋50º

Relative humidity:

less than 90%

Force of pressing key:

1~5N

Cooling mode:

Nature cooling

Installation Dimension

Figure size:

1060mm×1000mm×950mm

Weight:

210kgs
