Up/Down angle of swing arm:

±30°

Table size:

840mm×405mm

Table rotational angle:

90°

Table sliding movement:

330mm

Angle of rotation for chair:

±60°

Lifting height for chair:

150~200mm

Loading for chair:

70~150kgs

Lifting height for pillow:

＋150mm

Backrest obliquity:

90°~135°or 140°

Electrical Parameters

Engine power:

55W 220V AC

Light luminaire:

16W 110V/220V AV

Fuse:

5A 250V AC

Power without load:

1W

Pressure test:

2KV

Main wire:

10A 250V

Working mode:

S1

Working temperature:

－30º~＋50º

Relative humidity:

less than 90%

Force of pressing key:

1~5N

Cooling mode:

Nature cooling

Installation Dimension

Figure size:

1140mm×1000mm×2030mm

Weight:

165kgs
