| Sphere -29.00D~+26.75D,(step:0.12D/0.25D/0.5D/1D/2D/3D) |
| Cylinder 0.00D~8.75D(step:0.25D/0.5D/1D/2D/3D) |
| Cylinder Axis 0。~180。(step：1/5/15/30/45。) |
| PD Far:48~80mm Near:45~75mm (Step:0.5/1.0mm) |
| Working distance 35~70 cm (step:5cm) |
| Prism 0~20△(step 0.1△/0.2△/0.5△/1△/2△) |
| Jackson cross cylinder Jackson cross cylinder 0.25D Jackson cross cylinder 0.50D |
| Dual cross cylinder (separation prism) |
| Ophthalmoscope +1.5D,+2.0D(Measuring distance 67cm,50cm) |
| Size and weight |
| Body of main engine 362(Width) *83(Depth) *299(Height) mm,3.5kg |
| Keyboard 215(Width) *230(Depth) *226(Height) mm,1.5kg |
| Junction box 266(Width) *72(Depth) *240(Height) mm,1.3kg |
| Voltage AC100~240V,50/60Hz |
| Power 90VA |
| Auxiliary lens |
| Pinhole lens ∅1mm |
| Maddox Right eye(horizon), Left eye(vertical) |
| Red and green lens Right eye(red), Left eye(green) |
| Polaroid Right eye(135。,45。), Left eye(45。,135。) |
| Separation prism Right eye(6△BU), Left eye(10△BI) |
Solid suprachiasmatic cylinder Jackson Cross Cylinder±0.5D,Axis fixation 90。 |
| Visual degree 32。 |
